EL5RICA - 5" Aluminum Airtight IC Remodel Housing - 75W Max. - 120V - Medium Base PAR Lamps - Socket Bracket - Silver
Regular price
$13.93
Part Number: EL5RICA
5" Aluminum Airtight IC Housing. Compatible with Medium Base PAR Lamps up to 75W Max.
Wattage - 75w Max. Voltage - 120v Includes - Socket Bracket Bulb Type - Medium Base (E26) PAR Lamps Trims Sold Separately!
Height - 7 3/8" Width - 6 5/8" Length - 12 5/8"
5" Airtight IC Remodel Housing with Socket Bracket
Housing adjusts in frame to accommodate up to 1 1/4" ceiling thickness
IC Airtight for direct contact with insulation, for use in IC and non-IC applications
Integral thermal protector guards against improper lamping
Four remodel clips secure housing and accommodate various ceiling thicknesses
Adjustable socket bracket allows for different lamp types/sizes and proper and consistent lamp positioning
Pre-wired junction box provided with 1/2" and 3/4" knockouts and with removable access plate
Compatible with ELCO 5" Line Voltage PAR trims
3 year limited factory warranty
UL Listed for Feed Through
UL listed for Direct Contact with insulation and Combustible Material
UL Listed for Damp/Wet Locations with Wet Location Rated Trims (EL512, EL513, EL514, EL516)
Airtight per ASTM E-283
Install a JA8-2016-E Lamp/Luminaire for Tile 24 Compliance
Tech Specs
Material
Aluminum Housing
Construction Type
Remodel
Compatible Lamps
Medium Base (E26) PAR (Sold Separately!)
Voltage
120V
Installation
Four Remodel Clips/Pre-Wired Junction Box Provided with 1/2" and 3/4" Knockouts
Approval Type
UL - Damp locations, UL - Feed-through wiring, UL Listed For Direct Contact - Airtight Per ASTM E-283 - Install a JA8 Title 24 2016-E Lamp/Luminaire for Title 24 Compliance
